应用与详细资料/Brief Introduction：

该线由渐渐式挤出机螺杆洗瓶烘箱二合一机、原浆、油类液分装轧盖机二台手机单机游戏结构，可以分为拆洗、空气干燥消毒和分装封好三大做工作区，全新可一体化产量，也可手机单机游戏动用。可做完淋水、声波频率波拆洗、冲水、冲气、烘箱消毒、放置冷却、分装、理盖、戴盖、轧盖等生产工艺。The line is made up of two single machine, one straight-line screw bottle washing and drying machine and one oral liquid filling and capping machine. The line is divided into cleaning, drying, sterilization and filling sealing three workspace, all can joint production, also can use single. It can complete water spray, ultrasonic cleaning, water flushing, air flushing, drying sterilization, cooling, filling, cap arranging, capping, sealing, etc.

共同点/Characteristic：

主要采用彩超波擦洗及水雾循环交替擦拭、远红外气温无菌、多头多碇分装与密封等工艺。整线三级联动自動调节。操作使用简短便捷，保持了电气一体机化。Using ultrasonic cleaning and water washing alternately, far-infrared high-temperature sterilization, such as long filling and sealing technology. The automatic control of the whole line linkage. Simple and convenient operation, electromechanical integration is realized.

能力性能参数/ Technical Parameters：

生产能力technical parameters	80-150瓶/分80-150 bottles/min
可用于规格型号 Cutting dimension	5-20ml
电  容  量Amount of electric capacity	💯65Kw(这之中很正常上班36Kw)(including normal working 36 kw)
机器设备净重量machine net weight	6800Kg
外形尺寸boundary dimension	9650×2360×1900mm（长×宽×高）(length x width x height)
